3051CD5A02A1AH2B8K5 Pressure Transmitter Manifold Providing Customized Support ODM Suitable

Product Description:

The Pressure Transmitter Manifold, including models such as the 3051CD2A02A1JM6K5S5Q4 and 3051CD5A02A1AH2B8K5 from Emerson, represents a pinnacle of engineering excellence designed to meet the rigorous demands of modern industrial processes. Engineered for precision, durability, and versatility, this manifold is an essential component for accurate pressure measurement and control in a wide range of applications.
One of the key features of this Pressure Transmitter Manifold is its advanced communication protocol compatibility. It supports multiple industry-standard communication protocols including 4-20 mA HART®, WirelessHART®, FOUNDATION™ Fieldbus, PROFIBUS® PA, and 1-5 V Low Power HART®. This extensive protocol support ensures seamless integration with existing control systems and facilitates real-time data transmission, enabling enhanced process monitoring and automation. Whether you are upgrading an older system or implementing a new one, the manifold’s flexible communication options provide unmatched connectivity and interoperability.
Designed to operate under high-temperature conditions, the Pressure Transmitter Manifold is ideal for media with elevated temperatures, making it suitable for challenging environments such as chemical processing, oil and gas, and power generation industries. This capability ensures reliable performance and longevity, even when exposed to thermal stress, thereby reducing downtime and maintenance costs.
The manifold boasts an impressive range down capability of up to 150:1, which allows for highly precise pressure measurement across a wide span of operating pressures. This broad rangeability ensures that the device can be employed in diverse applications, from low-pressure monitoring to high-pressure process control, without compromising accuracy or sensitivity. Such flexibility makes it a cost-effective solution by reducing the need for multiple transmitters and simplifying inventory management.
Material selection is critical for the durability and chemical compatibility of pressure transmitters, and this manifold excels in this regard. It is constructed from premium materials including 316L stainless steel (SST), Alloy C-276, Alloy 400, tantalum, and gold-plated variants of 316L SST and Alloy 400. These materials provide exceptional resistance to corrosion, abrasion, and chemical attack, ensuring reliable operation in corrosive and harsh process environments. The availability of gold-plated options further enhances conductivity and corrosion resistance, suitable for highly specialized applications.
Understanding that every industrial setup has unique requirements, Emerson offers customized support for the Pressure Transmitter Manifold through OEM (Original Equipment Manufacturer) and ODM (Original Design Manufacturer) services. This customization capability allows clients to tailor the manifold’s specifications, materials, and configurations to perfectly match their process needs, ensuring optimal performance and integration. Whether it’s adapting to specific flange sizes, connection types, or communication protocols, Emerson’s customization options provide a highly flexible solution.
Models such as the 3051CD2A02A1JM6K5S5Q4 and 3051CD5A02A1AH2B8K5 exemplify Emerson’s commitment to technological innovation and quality. These manifolds deliver superior accuracy, reliability, and ease of use, making them the preferred choice for industries requiring stringent pressure measurement standards. By combining robust construction, advanced communication capabilities, and extensive customization options, the Pressure Transmitter Manifold from Emerson stands out as a vital instrument for enhancing process safety, efficiency, and control.
In summary, the Emerson Pressure Transmitter Manifold is an advanced, versatile, and reliable solution that meets the needs of high-temperature media environments and offers broad communication protocol compatibility, exceptional rangeability, and superior material options. With OEM and ODM customization support, it ensures that your pressure measurement system is not only accurate but also perfectly aligned with your specific industrial requirements.

Features:

• Product Name: Pressure Transmitter Manifold
• Compatible with Rosemount™ 3051 Coplanar™ Pressure Transmitter
• Model: Rosemount 3051CD3A22A1AB4M5Q4 + 305RC32 5-Valve
• Mounting Type: Direct Mount
• Environmental Humidity: 0-100%
• Diagnostics Features:
  • Basic Diagnostics
  • Process Alerts
  • Loop Integrity Diagnostics
  • Plugged Impulse Line Diagnostics
• Color: Blue
• Material Options:
  • 316L SST
  • Alloy C-276
  • Alloy 400
  • Tantalum
  • Gold-plated 316L SST
  • Gold-plated Alloy 400

Technical Parameters:

Applications:

The Rosemount Pressure Transmitter Manifold, model number 3051CD0A22A1AM5B4DFE5, is an advanced differential pressure transmitter designed for a wide range of industrial applications. Manufactured in China and constructed from high-quality materials such as 316L stainless steel, Alloy C-276, Alloy 400, Tantalum, and gold-plated variants of 316L SST and Alloy 400, this product ensures exceptional durability and resistance to harsh environments. Its robust construction makes it ideal for applications involving high temperature media, providing reliable and accurate pressure measurements under demanding conditions.
This manifold is perfectly suited for critical process control scenarios across industries such as oil and gas, chemical processing, power generation, and water treatment. Its compatibility with differential pressure transmitter models like the 3051CD3A22A1AM5B4L1Q4 and 3051CD2A02A1JM6K5S5Q4 enables seamless integration into existing systems, facilitating precise flow, level, and pressure monitoring. The manifold's output supports 4-20 mA HART communication protocol, allowing for real-time data transmission and enhanced process control through digital communication.
The Rosemount 3051CD0A22A1AM5B4DFE5 manifold also offers comprehensive diagnostic capabilities, including basic diagnostics, process alerts, loop integrity diagnostics, and plugged impulse line diagnostics. These features provide operators with critical insights into system performance and help in early detection of potential issues, minimizing downtime and maintenance costs. Additionally, the product supports OEM and ODM customization, enabling tailored solutions to meet specific process requirements.
Typical application occasions for this pressure transmitter manifold include monitoring differential pressure in high-temperature steam systems, chemical reactors, and pipeline flow measurement where accuracy and reliability are paramount. It is also widely used in environments requiring corrosion resistance and high mechanical strength, such as offshore platforms and refineries. The manifold’s ability to withstand extreme temperatures and aggressive media ensures long-term stable operation in challenging scenarios.
Overall, the Rosemount 3051CD0A22A1AM5B4DFE5 pressure transmitter manifold is a versatile and reliable solution for industries seeking high-performance differential pressure measurement with advanced diagnostic functionalities and customizable options, making it an indispensable tool for modern process control systems.
